Introducing Cryogenic's Prover Tank, a reliable and accurate solution designed to meet the diverse needs of checking commercial bulk measures, vehicle tanks, bulk meters, and more.
Available in capacities ranging from 50 liters to 5000 liters, these tanks are constructed with different materials to ensure durability and precision. All designs adhere to the IS - 2341 code, certified under weights and measures standards.
1. Versatile Capacity Range:
Choose from a wide range of capacities, spanning 50 liters to 5000 liters, providing flexibility to meet various testing requirements.
2. Material of Construction Options:
Prover tanks are constructed with different materials, ensuring compatibility with various liquids and enhancing overall durability.
3. Compliance with Standards:
Designed in accordance with the IS – 2341 code, Cryogenic's Prover Tanks are certified under weights and measures standards, ensuring accuracy and reliability in measurement.
4. Stationary and Mobile Options:
Tailor your testing setup with the choice of stationary or mobile Prover Tanks, catering to different applications such as checking commercial bulk measures or on-site calibration of measuring devices.
5. Consistent Accuracy:
Maintain the same high level of accuracy and quality in Prover Tanks as in smaller test measures, providing a reliable and cost-effective means to measure the output accuracy of liquid metering equipment.
6. Ease of Use:
Provers are designed to be user-friendly, offering a straightforward and efficient method for verifying the precision of liquid metering equipment.
7. On-Site Calibration Capability:
Portable in nature, these Prover Tanks enable on-site calibration of measuring devices, ensuring fairness and accuracy in liquid transactions, especially crucial for oil companies.
8. Proven Track Record:
Cryogenic has a commendable track record, having supplied over 200 units by 2014, showcasing our commitment to delivering reliable and high-quality Prover Tanks.
Cryogenic's Prover Tank is a dependable and portable solution for ensuring the accuracy of measuring devices on-site, providing a cost-effective and efficient means to uphold fairness and precision in liquid transactions. Elevate your calibration processes with a proven and trusted solution from Cryogenic.
| M - Material of construction |
|---|
| M1. IS 2062 GR.B |
| M2. ASTM A 516 GR.70 |
| M3. ASTM A 240 TP 304 |
| M4. ASTM A 240 TP 316 |
| C - Capacity of prover tank |
|---|
| C1. 50 litres |
| C2. 100 litres |
| C3. 200 litres |
| C4. 500 litres |
| C5. 1000 litres |
| C6. 1500 litres |
| C7. 2000 litres |
| C8. 5000 litres |
| C9. Any Customzed Capacity |
| IO - Inlet / Outlet connection |
|---|
| IO1. 1" (25 mm) |
| IO2. 2" (50 mm) |
| IO3. 3" (80 mm) |
| IO4. 4" (100 mm) |
| IO5. 3" Inlet/ 4" Outlet (80 mm / 100 mm) |
| IO6. 6" (150 mm) |
| IO7. As Per Customer Requirements |
| T - Type of prover tank |
|---|
| T1 Fixed type with skid base |
| T2 Mobile prover tank with Leveling jack |
| T3 Mobile prover tank for Rail Wagon - Suitable for ail Track |
| A - Accessories |
|---|
| A1 With decanting pump and motor |
| A2 Flexible hose - 3 mtr length - 1 no. |
| A3 DOL starter for motor |
| A4 Temperature Gauge (3 location) |
| A5 Inlet / Outlet ball valve |
| A6 32 Amp Switch and Socket |
| A7 API Coupler With TTML Flange For Bottom Loading |
| * Pump as per Manufacturers standard and Motor will be IP 55 Flame Proof |
